Hydraulic Winch - Recovery Pro
Hydraulic Winch

Product Specifications

Hydraulic Winches
  • 20,000lb (9,072kg) 12V wireless
  • 25m x 14mm galvanized steel wire rope.
  • 1/2 inch clevis hook with safety catch
  • Heavy-duty 4-way roller fairlead integrated to frame;
  • One-piece CNC machined billet aluminium hawse fairlead.
  • Specifications.
  • Flow 50-60 l/min
  • Pressure 10.8Mpa (108 Bar)
  • Pressure Hose Connections 18mm/1.5mm
  • Gear Train 3 Stage Planetary
  • Gear Reduction Ratio 32:1
  • Clutch Sliding Ring Gear
  • Braking Action Automatic
  • No Load Line Speed 6.5m/min (21.3 ft/min)
  • Drum Size Diameter 88mm Length 222mm
  • Drum Finish Black; painted.
  • Winch Finish Original Orange powder-coated
  • Ultra-tough three-stage gearbox with hardened steel gears.
  • Winch casing machined from billet steel for maximum impact protection.
  • Through-drum rope attachment with grub screw clamp for maximum security.
  • Sliding ring gear free-wheel clutch.
  • Compatible with the full WINCHMAX range of wireless remote controls.
  • Big grip controller for power in/out with extra-long 4.5m wander lead.
  • Mounting Bolt Pattern 10.00” x 4.50” (254 x 114.3mm)
  • High tensile fixing bolt kit.
  • Weight (GW) 70kg (154lb)
  • Overall Dimensions (LxWxH) 548 x 196 x 249mm
  • CE certified & built to ISO9001 quality management system requirements.
Related products



Hydraulic Winch

£1,200.00 In Stock (321 available)
Minimum Order Value: £923.00



Description

Hydraulic Winch, 25 x 14 Steel Rope, Twin Wireless Remote Control
20,000lb (9,072kg)
20,000lb Hydraulic Z Winch. 25m x 14mm Steel Rope.
